| Measurement mode |
Transmit echo |
Standard measurement: For Normal thickness measurement. Minimum measurement: For curved surface Differential measurement: Displays the difference from the actual thickness measurement and a user entered reference valueAverage
Average measurement : 2-9 point selectable
Limit measurement: Min. Max setting and alarm |
| Echo-Echo |
The metal wall thickness is accurately and quickly measured in spite of
surface coating |
| Scan |
Displays min. or Max. thickness value at 10 measurements per second while
also display actual thickness (Ideal for high temp. thickness readings) |
| Probe identify |
Auto |
| Probe zero |
Auto at power up and continuously during the measurement |
| Gain adjust |
Auto gain adjustment |
| Manual gain adjustment, low, standard and high |
| Memory |
Up to 5000 groups(Order No.950-1043) |
| Measuring Range |
4-20mm(0.157-0.787inch) Echo-Echo
0.65-400mm (0.025-15.748inch) (range depends on probe-material combination) |
| Resolution |
0.01mm for thickness up to 99.99mm，0.1mm for thickness above 99.99mm |
| Information Display |
Measurement reading, Probe type, Velocity, measurement mode,measurement Symbol, Battery |
|
| Velocity range |
1000m/s-9999m/s |
| Velocity measurement |
Simply calibrate when a material’s velocity is unknow |
| Display |
128 x 64 graphics LCD monochrome |
| Battery Type |
2 AA Alkaline |
| Battery Life |
Up to 50 hours (without Backlight) |
| Interface |
USB |
| Shut off |
Auto, 2 Min., 5Min, or never shut off selectable |
| Working Temperature |
-20℃-50℃ |
| Units |
mm/inch |
| Size |
115mm (L)x 64mm(W) x 27mm(H) |
| Weight |
220g |
