Features:
*Developed Model of 950-1067
*Compact metal case，suitable for use under poor working conditions. Test at any angle, even upside down.
*Wide measuring range. It can measure the hardness of all metallic materials. Direct display of hardness scales HRB, HRC, HV, HB, HS, HL
*Large screen(128*64 dot matrix LCD), showing all functions and parameters. With EL background light.
*Software calibration function.
*Software to connect with PC via RS232 port. Micro printer support.
*Outline :132mm*76mm*33mm Weight：345g

Technical Specifications:
*Measuring range：(170-960)HLD,(17-68.5)HRC,(19-651)HB,(80-976)HV,(30-100)HS,(59-85)HRA,(13-100)HRB
*Measuring direction：360degree(up,down,horizontal,slanting up,slanting down)
*Hardness Scale：HL,HB,HRB,HRC,HRA,HV,HS
*Display：dot matrix LCD，128*64 dots
*Data memory：max. 500 groups（relative to impact times 32 every group）
*Working voltage：3V（2 AA size alkaline battery）
*Continuous working period：about 50 hours（With backlight off）
*Communication interface：RS232

Error and repeatability of displayed value:

Standard Kit:
*Main body 1piece
*D type impact device 1piece
*Standard test block() 1piece
*Cleaning brush 1piece
*Small support ring 1piece
*Alkaline battery 2pieces
*Manual 1piece
*Instrument case 1piece
*DataPro software for MH210 1piece
*Communication cable 1piece
*Tool for battery cover 1piece
*Belt 1piece
*Min-printer 1piece
*Print cable 1piece

Optional Accessories:
*Cleaning brush (II) for use with other type of impact device 1piece
*Impact device 7pieces
*Tool for changing impact ball 1piece
*Support ring 1piece
*Impact ball / body 1piece

Main Application:
*Die cavity of molds
*Bearings and other parts
*Failure analysis of pressure vessel, steam generator and other equipment
*Heavy work piece
*The installed machinery and permanently assembled parts.
*Testing surface of a small hollow space
*Material identification in the warehouse of metallic materials
*Rapid testing in large range and multi-measuring areas for large-scale work piece
