Features:
*Compact plastic case，suitable for use under poor working conditions. Test at any angle, even upside down.
*Wide measuring range. It can measure the hardness of all metallic materials. Direct display of hardness scales HRB, HRC, HV, HB, HS, HL
*Large screen (segment LCD), showing all functions and parameters. With EL background light.
*Large capacity memory could store 100 groups information.
*Datapro Software to connect with PC via RS232 port. Micro printer support
*Software calibration function.

Technical Specifications:
*Measuring range：
(170-960)HLD,(17-68.5)HRC,(19-651)HB,(80-976)HV,(30-100)HS,(59-85)HRA,(13-100)HRB
*Measuring direction：360degree(up,down,horizontal,slanting up,slanting downp,down,horizontal,slanting up,slanting down)
*Measuring materials: steel and cast steel, cold work tool steel, stainless steel,grey cast iron, nodular cast iron,cast aluminium allorys,brass(coppper-zinc alloys), bronze(copper-alluminium alloys/copper-tin alloys),wrought copper alloys
*Hardness Scale：HL,HB,HRB,HRC,HRA,HV,HS
*Display：segment LCD
*Data memory：max. 100 groups（relative to impact times 32～1）
*Working voltage：3V（2 AA size alkaline battery）
*Continuous working period：about 100 hours（With backlight off）
*Communication interface：RS232

Standard Kit:
*Main unit 1piece
*D type impact device 1piece
*Standard test block 1piece
*Cleaning brush (I) 1piece
*Small support ring 1piece
*Alkaline battery 2pieces
*Manual 1piece
*Instrument package case 1piece

Optional Accessories:
*Cleaning brush (II) for use with G type impact device 1piece
*Impact devices and support rings 1piece
*DataPro software 1piece
*Communication cable 1piece
*Micro Printer 1piece
*Print cable 1piece

Main Application:
*Die cavity of molds
*Bearings and other parts
*Failure analysis of pressure vessel, steam generator and other equipment
*Heavy work piece
*The installed machinery and permanently assembled parts.
*Testing surface of a small hollow space
*Material identification in the warehouse of metallic materials
*Rapid testing in large range and multi-measuring areas for large-scale work piece
